Max. SPL @ 10 % THD

125 dB halfspace

Max. SPL Peak @ 10 % THD

130 dB halfspace

Max SPL calculated

133 dB halfspace

Frequency response +/- 3 dB

61 Hz – 16 kHz

Frequency response -10 dB

57 Hz – 18 kHz

Amplifier output (Peak Power)

1200 W

Amplifier type

Class D – biamped

Active protection circuits

Peak and RMS sound limiter (separated for HF and LMF)

Bass speaker

–

Low/mid-range speaker

1x 15″, 2.5″ voice coil

HF Driver

1″, 1″ voice coil

Horn characteristics

90° x 55° CD horn

Crossover frequency active

2.5 kHz FIR X-over with 48 dB/oct.

Audio connectors in

1x XLR/jack combo balanced

Audio connectors out

1x XLR thru bal.

Sensitivity switch

Mic/Line

Tone control

Tone controller (Music/Speech)

Filter presets

Flat/Boost

Setup angle

42°

Pole mount

DuoTilt 3/7

Rigging points

–

Carrying handles

2, MultiGrip

Housing

MDF

Finish

Black acrylic enamel

Front grille

1.5 mm metal grille backed with black acoustic foam

Dimensions (WxHxD)

47.5 x 63 x 45.5 cm

Weight

24.9 kg / 54,9 lbs
